İNKÜBATÖR
DOĞAL HAVA SİRKÜLASYONLU (SMART-LAB CONTROLLER)
|
Models |
ThermoStable SIG-32 |
ThermoStable SIG-50 |
ThermoStable SIG-105 |
ThermoStable SIG-155 |
|
|
Capacity |
32 Lit. |
50 Lit. |
105 Lit. |
155 Lit. |
|
|
Dimension (w×d ×h) |
Interior (mm) |
312×290×360 |
370×350×420 |
485×410×535 |
550×475×600 |
|
Exterior (mm) |
458×477×624 |
518×537×701 |
635×595×841 |
700×660×906 |
|
|
Heater Power |
150W |
200W |
300W |
400W |
|
|
|
Range |
Ambient Temperature +5℃ to 70℃ |
|||
|
Fluctuation |
± 0.2℃ at 37℃, ± 0.3℃ at 50℃ |
||||
|
Variation |
± 0.6℃ at 37℃, ± 1.0℃ at 50℃ |
||||
|
Sensor |
PT 100 |
||||
|
Control Resolution |
±0.1℃ |
||||
|
Heat-up Time |
25 min. to 37 ℃ , 40 min. to 50 ℃ |
30 min. to 37 ℃ , 40 min. to 50 ℃ |
|||
|
Recovery Time (Door open 30sec) |
8 min. to 37 ℃ 12 min. to 50 ℃ |
10 min. to 37 ℃ 15 min. to 50 ℃ |
|||
|
Controller |
Smart-LabTM Controller |
||||
|
RS232 Port |
Available to connect with PC |
||||
|
Display |
4″Full Touch Screen TFT LCD |
||||
|
Timer |
99hr 59 min (delay/continuous function) |
||||
|
Material |
Internal |
Stainless steel (#304) |
|||
|
External |
Powder Coated steel |
||||
|
Inner Door |
Inner Tempered Glass Door |
||||
|
Shelves |
2ea of Teflon-coated steel Wire Shelves included, Load per Shelf : 16 kg |
||||
|
Ventilation |
1ea of Ventilation hole with Stainless steel Cap, Hole Diameter 40mm |
||||
|
Circulation |
Gravity Convection Type |
||||
|
Safety device |
Over Temp. and Over Current Protector, Sensor Error Detector |
||||
|
Others |
UL/CUL Certified, CE Certified, GD-mark Storage Function (Temp. and Time) Alarm (Error Status and Timer-end) |
||||
|
Net Weight (kg) |
32 |
40 |
59 |
71 |
|
|
Packing Size (w×d×h) (mm) |
568×592×698 |
628×652×775 |
731×710×1,018 |
796×775×1,083 |
|
|
Shipping Weight (kg) |
39 |
53 |
67 |
78 |
|
|
Power Consumption |
159 W |
169.9 W |
292.9 W |
420.5 W |
|
|
Energy Consumption, at 37°C , at 50°C |
34 Wh |
41 Wh |
63 Wh |
99 Wh |
|
|
81 Wh |
103 Wh |
152 Wh |
212 Wh |
||
|
Power Supply |
1Phase 120V, 60Hz or 230V, 50/60Hz |
||||
