Technical data for steam distillers

	S 1	S 2	S 3	S 4	S 5
Voltage	230 VAC/115 VAC
Frequency	50/60 Hz
Power consumption	1700 W
Current consumption	9 A/18 A
Cooling water consumption	approx. 5 l/min
Distillation time	approx. 2 - 4 min per sample
Storage container	Any size required. Recommendation: behrotest® KAS canister sets
Interface	USB
Display	LCD
Programs	1	1	10	100	100
Dimensions (W x H x D in cm)	approx. 41 x 67.5 x 41
Weight	approx. 32 kg	approx. 34 kg	approx. 35 kg	approx. 35 kg	approx. 36 kg
Titrator connection	no	no	no	no	yes

Features of the various units

	S 1	S 2	S 3	S 4	S 5
Automatic addition of H2O	–	+	+	+	+
Automatic addition of NaOH	+	+	+	+	+
Automatic addition of H3BO3	–	–	–	+	+
Manual addition of H2O	–	+	+	+	+
Manual addition of NaOH	+	+	+	+	+
Manual addition of H3BO3	–	–	–	+	+
Automatic extraction of the sample residues	–	–	+	+	+
Number of programs	1	1	10	99	99
Titrator connection option	–	–	–	–	+

Programmable reaction time	+
Programmable distillation time	+
Automatic steam generation	+
Adjustable steam output (40% – 100%)	+
Separate purging program	+
Display language selectable by user	+
Optical error indications	+
Acoustic error indications	+
Door safety contact switch	+
USB interface	+
Standby mode between distillations	+
Level monitoring for the canister set	+
Different glass digestion tubes can be used	+
